Title
Hondata FlashPro RDX 2007-2012 (CARB)
The FlashPro allows datalogging and limited tuning of the 2007-2012 US Acura RDX turbo. It includes Windows based software called FlashPro Manager.
EPA/CARB Status
California emissions compliant (CARB EO D-742-1), which allows this product to be used on street vehicles within the USA.
Important Note
This FlashPro allows limited tuning or preset calibrations. For competition vehicles we recommend the FP-RDX-US FlashPro as that FlashPro allows full tuning.
Sales Market
This FlashPro can only be sold to US/Canada addresses.
Features
- Programmable ECU interface.
- Connects via OBDII diagnostic port.
- USB 2.0 connection
- Works with Laptop or Desktop
- No ECU modification necessary.
- 20 hours on board datalogging memory.
- Security Password.
- FlashProManager Windows software.
- Check and clear diagnostic codes.
- Custom laptop gauges.
- Dual calibration storage - upload from one of two calibrations stored in the FlashPro
Dyno
What sort of improvements can I expect if my car is modified?
This RDX had the second catalytic converter removed, was fitted with a custom 3" exhaust, an intake and tuned. Gains were in the order of 47 lb-ft torque and 47 hp.
What sort of improvements can I expect if my car is stock?
This stock 07 Acura RDX gained 26 hp solely from FlashPro tuning. This is the tuning previously used in the RDX reflash and is now included as a base calibration. Gains were made from altering the boost, advancing the ignition, and leaning the mixture.
How much can I increase the boost?
The RDX MAP sensor will read up to 26 psi of boost but no testing was done above 15 psi.
We raised midrange boost on our test RDX from 14-15 psi. Boost at peak RPM was raised from 8 to 12 psi. At 12 psi the stock injectors were very close to maximum duty cycle. More boost requires larger injectors. Base calibrations are provided for 600 and 800cc injectors. Boost is also limited by fuel octane. All tests were done with California 91 octane.
Videos
We've put together a series of training videos to describe the function and use of the FlashPro. View the videos in High Definition Full Screen to view the screen shots.
FlashPro Introduction
Hondata's new generation programming tool for the 06 - 09 US Civic Si, the Japanese 06-09 Civic Type R and the European 07-09 Civic Type R. A brief introduction.
FlashPro getting started
This video covers the installation the FlashPro Manager software, the USB drivers, software registration and upload of a calibration.
Live Tuning
One of the latest features added to FlashPro, live tuning gives you the ability to tune your Honda or Acura on the fly without switching off the engine. Live tuning simplifies part throttle tuning and significantly reduces the time and cost of tuning your car.
Race Calibration
Hondata has developed a Race calibration which allows you to tune with the MAP sensor and bypass the limitations of the AFM sensor. A look at the tuning principles for forced induction on a modern return-less fuel system.
Datalogging and Air fuel ratios
A look a the extensive datalogging capabilities of the FlashPro and the many ways in which to examine your engine data. We touch on the datalogging of the air fuel ratios and how you can use it to adjust your tuning.
Bluetooth
How do I tell if my FlashPro supports Bluetooth?
From July 2013 some FlashPros shipped from Hondata including Bluetooth.
From Jan 1 2014, all FlashPros shipped from Hondata include Bluetooth.
FlashPros sold before the dates in the table below do not support Bluetooth. To confirm if your FlashPro supports Bluetooth follow this procedure:
- Launch FlashPro Manager
- Plug in the FlashPro to your USB port.
- Press the FlashPro button, tab, then hardware.
- If Bluetooth is present, Yes will be indicated.
- If you do not see 'Bluetooth present' at all, then you are using an older version of FlashProManager and need to update. This does not mean that you don't have a FlashPro with a Bluetooth radio.
- If 'Bluetooth present' is No, your FlashPro does not have Bluetooth. You may upgrade your FlashPro is you wish.
| FlashPro Model | Sold after Date |
| 06-11 Civic Si US | 11/7/2013 |
| 06-11 Civic Si /Type R International | 9/27/2013 |
| 06-11 Civic R18 | 8/20/2013 |
| 06-up S2000 US | 7/23/2013 |
| 06-up S2000 International | 10/4/2013 |
| TSX US | 8/22/2013 |
| 2012+up Civic Si & ILX | 7/29/2013 |
| CR-Z International | 10/17/2013 |
| TL US | 10/8/2013 |
| Accord Int. All FlashPros compatible | 7/9/2013 |
| RDX US All FlashPros compatible | 9/3/2013 |
| CR-Z US | 12/17/2013 |
| Fit US | 12/3/2013 |
The FlashPro allows datalogging and limited tuning of the 2007-2012 US Acura RDX turbo. It includes Windows based software called FlashPro Manager.
EPA/CARB Status
California emissions compliant (CARB EO D-742-1), which allows this product to be used on street vehicles within the USA.
Important Note
This FlashPro allows limited tuning or preset calibrations. For competition vehicles we recommend the FP-RDX-US FlashPro as that FlashPro allows full tuning.
Sales Market
This FlashPro can only be sold to US/Canada addresses.
Features
- Programmable ECU interface.
- Connects via OBDII diagnostic port.
- USB 2.0 connection
- Works with Laptop or Desktop
- No ECU modification necessary.
- 20 hours on board datalogging memory.
- Security Password.
- FlashProManager Windows software.
- Check and clear diagnostic codes.
- Custom laptop gauges.
- Dual calibration storage - upload from one of two calibrations stored in the FlashPro
Dyno
What sort of improvements can I expect if my car is modified?
This RDX had the second catalytic converter removed, was fitted with a custom 3" exhaust, an intake and tuned. Gains were in the order of 47 lb-ft torque and 47 hp.
What sort of improvements can I expect if my car is stock?
This stock 07 Acura RDX gained 26 hp solely from FlashPro tuning. This is the tuning previously used in the RDX reflash and is now included as a base calibration. Gains were made from altering the boost, advancing the ignition, and leaning the mixture.
How much can I increase the boost?
The RDX MAP sensor will read up to 26 psi of boost but no testing was done above 15 psi.
We raised midrange boost on our test RDX from 14-15 psi. Boost at peak RPM was raised from 8 to 12 psi. At 12 psi the stock injectors were very close to maximum duty cycle. More boost requires larger injectors. Base calibrations are provided for 600 and 800cc injectors. Boost is also limited by fuel octane. All tests were done with California 91 octane.
Videos
We've put together a series of training videos to describe the function and use of the FlashPro. View the videos in High Definition Full Screen to view the screen shots.
FlashPro Introduction
Hondata's new generation programming tool for the 06 - 09 US Civic Si, the Japanese 06-09 Civic Type R and the European 07-09 Civic Type R. A brief introduction.
FlashPro getting started
This video covers the installation the FlashPro Manager software, the USB drivers, software registration and upload of a calibration.
Live Tuning
One of the latest features added to FlashPro, live tuning gives you the ability to tune your Honda or Acura on the fly without switching off the engine. Live tuning simplifies part throttle tuning and significantly reduces the time and cost of tuning your car.
Race Calibration
Hondata has developed a Race calibration which allows you to tune with the MAP sensor and bypass the limitations of the AFM sensor. A look at the tuning principles for forced induction on a modern return-less fuel system.
Datalogging and Air fuel ratios
A look a the extensive datalogging capabilities of the FlashPro and the many ways in which to examine your engine data. We touch on the datalogging of the air fuel ratios and how you can use it to adjust your tuning.
Bluetooth
How do I tell if my FlashPro supports Bluetooth?
From July 2013 some FlashPros shipped from Hondata including Bluetooth.
From Jan 1 2014, all FlashPros shipped from Hondata include Bluetooth.
FlashPros sold before the dates in the table below do not support Bluetooth. To confirm if your FlashPro supports Bluetooth follow this procedure:
- Launch FlashPro Manager
- Plug in the FlashPro to your USB port.
- Press the FlashPro button, tab, then hardware.
- If Bluetooth is present, Yes will be indicated.
- If you do not see 'Bluetooth present' at all, then you are using an older version of FlashProManager and need to update. This does not mean that you don't have a FlashPro with a Bluetooth radio.
- If 'Bluetooth present' is No, your FlashPro does not have Bluetooth. You may upgrade your FlashPro is you wish.
| FlashPro Model | Sold after Date |
| 06-11 Civic Si US | 11/7/2013 |
| 06-11 Civic Si /Type R International | 9/27/2013 |
| 06-11 Civic R18 | 8/20/2013 |
| 06-up S2000 US | 7/23/2013 |
| 06-up S2000 International | 10/4/2013 |
| TSX US | 8/22/2013 |
| 2012+up Civic Si & ILX | 7/29/2013 |
| CR-Z International | 10/17/2013 |
| TL US | 10/8/2013 |
| Accord Int. All FlashPros compatible | 7/9/2013 |
| RDX US All FlashPros compatible | 9/3/2013 |
| CR-Z US | 12/17/2013 |
| Fit US | 12/3/2013 |
