Hondata FlashPro CRZ US (CARB)
The FlashPro allows datalogging and limited tuning for your CR-Z. It includes Windows based software called FlashProManager. The FlashPro connects from your laptop's USB port to your vehicles diagnostic port.
EPA/CARB Status
California emissions compliant (CARB EO D-742-1), which allows this product to be used on street vehicles within the USA.
Important Note
This FlashPro allows limited tuning or preset calibrations. For competition vehicles we recommend the FP-CRZ-US FlashPro as that FlashPro allows full tuning.
Sales Market
This FlashPro can only be sold to US/Canada addresses.
Features
- Programmable ECU interface.
- Connects via OBDII diagnostic port.
- USB 2.0 connection
- Works with Laptop or Desktop
- No ECU modification necessary.
- 20 hours on board datalogging memory.
- Security Password.
- FlashProManager Windows software.
- Check and clear diagnostic codes.
- Custom laptop gauges.
- Dual calibration storage - upload from one of two calibrations stored in the FlashPro
Dyno
Every map listed here has been comprehensively tuned for fuel and ignition for both part and full throttle. Listed here are dyno plots of most of the base maps provided with the FlashPro in PDF format. The tests give a good indication of the gains to be had from various bolt-ons.
All intake maps include adjustments to the Air Flow Meter data to achieve optimal part and full throttle air fuel ratios. No intake we tested gave the same air fuel ratio as stock.
Base maps are included for a variety of injector sizes to support high HP NA cars and forced induction.
Maps for injectors:
- 185cc - Stock
- 270cc - Honda V6 (plug in replacement)
- 310cc - RSX S / Civic Si (plug in replacement)
- 410cc - Acura RDX
- 450cc - Deatschworks
- 600cc - Deatschworks
- 800cc - Deatschworks
The Acura RDX injectors, for example should provide enough fuel to double the stock engine HP with forced induction. For R18 Civics with around 300HP we recommend a return line fuel system.
The dyno plot here indicates the gains you might see with a supercharger kit. Green line stock. Red dotted line 4 psi, red line 7 psi. These dyno tests were run with a stock cat-back which restricted power.
Stock Header
- Stock Tuned
- Injen CAI
- AEM CAI
- HKS SRI
Boosted
- HKS Supercharger
Videos
We've put together a series of training videos to describe the function and use of the FlashPro. View the videos in High Definition Full Screen to view the screen shots.
FlashPro Introduction
Hondata's new generation programming tool for the 06 - 09 US Civic Si, the Japanese 06-09 Civic Type R and the European 07-09 Civic Type R. A brief introduction.
FlashPro getting started
This video covers the installation the FlashPro Manager software, the USB drivers, software registration and upload of a calibration.
Live Tuning
One of the latest features added to FlashPro, live tuning gives you the ability to tune your Honda or Acura on the fly without switching off the engine. Live tuning simplifies part throttle tuning and significantly reduces the time and cost of tuning your car.
Race Calibration
Hondata has developed a Race calibration which allows you to tune with the MAP sensor and bypass the limitations of the AFM sensor. A look at the tuning principles for forced induction on a modern return-less fuel system.
Datalogging and Air fuel ratios
A look a the extensive datalogging capabilities of the FlashPro and the many ways in which to examine your engine data. We touch on the datalogging of the air fuel ratios and how you can use it to adjust your tuning.
Bluetooth
How do I tell if my FlashPro supports Bluetooth?
From July 2013 some FlashPros shipped from Hondata including Bluetooth.
From Jan 1 2014, all FlashPros shipped from Hondata include Bluetooth.
FlashPros sold before the dates in the table below do not support Bluetooth. To confirm if your FlashPro supports Bluetooth follow this procedure:
- Launch FlashPro Manager
- Plug in the FlashPro to your USB port.
- Press the FlashPro button, tab, then hardware.
- If Bluetooth is present, Yes will be indicated.
- If you do not see 'Bluetooth present' at all, then you are using an older version of FlashProManager and need to update. This does not mean that you don't have a FlashPro with a Bluetooth radio.
- If 'Bluetooth present' is No, your FlashPro does not have Bluetooth. You may upgrade your FlashPro is you wish.
| FlashPro Model | Sold after Date |
| 06-11 Civic Si US | 11/7/2013 |
| 06-11 Civic Si /Type R International | 9/27/2013 |
| 06-11 Civic R18 | 8/20/2013 |
| 06-up S2000 US | 7/23/2013 |
| 06-up S2000 International | 10/4/2013 |
| TSX US | 8/22/2013 |
| 2012+up Civic Si & ILX | 7/29/2013 |
| CR-Z International | 10/17/2013 |
| TL US | 10/8/2013 |
| Accord Int. All FlashPros compatible | 7/9/2013 |
| RDX US All FlashPros compatible | 9/3/2013 |
| CR-Z US | 12/17/2013 |
| Fit US | 12/3/2013 |
The FlashPro allows datalogging and limited tuning for your CR-Z. It includes Windows based software called FlashProManager. The FlashPro connects from your laptop's USB port to your vehicles diagnostic port.
EPA/CARB Status
California emissions compliant (CARB EO D-742-1), which allows this product to be used on street vehicles within the USA.
Important Note
This FlashPro allows limited tuning or preset calibrations. For competition vehicles we recommend the FP-CRZ-US FlashPro as that FlashPro allows full tuning.
Sales Market
This FlashPro can only be sold to US/Canada addresses.
Features
- Programmable ECU interface.
- Connects via OBDII diagnostic port.
- USB 2.0 connection
- Works with Laptop or Desktop
- No ECU modification necessary.
- 20 hours on board datalogging memory.
- Security Password.
- FlashProManager Windows software.
- Check and clear diagnostic codes.
- Custom laptop gauges.
- Dual calibration storage - upload from one of two calibrations stored in the FlashPro
Dyno
Every map listed here has been comprehensively tuned for fuel and ignition for both part and full throttle. Listed here are dyno plots of most of the base maps provided with the FlashPro in PDF format. The tests give a good indication of the gains to be had from various bolt-ons.
All intake maps include adjustments to the Air Flow Meter data to achieve optimal part and full throttle air fuel ratios. No intake we tested gave the same air fuel ratio as stock.
Base maps are included for a variety of injector sizes to support high HP NA cars and forced induction.
Maps for injectors:
- 185cc - Stock
- 270cc - Honda V6 (plug in replacement)
- 310cc - RSX S / Civic Si (plug in replacement)
- 410cc - Acura RDX
- 450cc - Deatschworks
- 600cc - Deatschworks
- 800cc - Deatschworks
The Acura RDX injectors, for example should provide enough fuel to double the stock engine HP with forced induction. For R18 Civics with around 300HP we recommend a return line fuel system.
The dyno plot here indicates the gains you might see with a supercharger kit. Green line stock. Red dotted line 4 psi, red line 7 psi. These dyno tests were run with a stock cat-back which restricted power.
Stock Header
- Stock Tuned
- Injen CAI
- AEM CAI
- HKS SRI
Boosted
- HKS Supercharger
Videos
We've put together a series of training videos to describe the function and use of the FlashPro. View the videos in High Definition Full Screen to view the screen shots.
FlashPro Introduction
Hondata's new generation programming tool for the 06 - 09 US Civic Si, the Japanese 06-09 Civic Type R and the European 07-09 Civic Type R. A brief introduction.
FlashPro getting started
This video covers the installation the FlashPro Manager software, the USB drivers, software registration and upload of a calibration.
Live Tuning
One of the latest features added to FlashPro, live tuning gives you the ability to tune your Honda or Acura on the fly without switching off the engine. Live tuning simplifies part throttle tuning and significantly reduces the time and cost of tuning your car.
Race Calibration
Hondata has developed a Race calibration which allows you to tune with the MAP sensor and bypass the limitations of the AFM sensor. A look at the tuning principles for forced induction on a modern return-less fuel system.
Datalogging and Air fuel ratios
A look a the extensive datalogging capabilities of the FlashPro and the many ways in which to examine your engine data. We touch on the datalogging of the air fuel ratios and how you can use it to adjust your tuning.
Bluetooth
How do I tell if my FlashPro supports Bluetooth?
From July 2013 some FlashPros shipped from Hondata including Bluetooth.
From Jan 1 2014, all FlashPros shipped from Hondata include Bluetooth.
FlashPros sold before the dates in the table below do not support Bluetooth. To confirm if your FlashPro supports Bluetooth follow this procedure:
- Launch FlashPro Manager
- Plug in the FlashPro to your USB port.
- Press the FlashPro button, tab, then hardware.
- If Bluetooth is present, Yes will be indicated.
- If you do not see 'Bluetooth present' at all, then you are using an older version of FlashProManager and need to update. This does not mean that you don't have a FlashPro with a Bluetooth radio.
- If 'Bluetooth present' is No, your FlashPro does not have Bluetooth. You may upgrade your FlashPro is you wish.
| FlashPro Model | Sold after Date |
| 06-11 Civic Si US | 11/7/2013 |
| 06-11 Civic Si /Type R International | 9/27/2013 |
| 06-11 Civic R18 | 8/20/2013 |
| 06-up S2000 US | 7/23/2013 |
| 06-up S2000 International | 10/4/2013 |
| TSX US | 8/22/2013 |
| 2012+up Civic Si & ILX | 7/29/2013 |
| CR-Z International | 10/17/2013 |
| TL US | 10/8/2013 |
| Accord Int. All FlashPros compatible | 7/9/2013 |
| RDX US All FlashPros compatible | 9/3/2013 |
| CR-Z US | 12/17/2013 |
| Fit US | 12/3/2013 |
